Trolley Mounted Mechanical Foam Extinguisher

MODEL NO

SE-SP-MF-6

SE-SP-MF -9

Capacity

6L

9L

Diameter ( mm)

150

175

Height ( mm)

550

605

Empty Weight (kg )

3.5

4.7

Filled Weight (kg)

9.5

13.7

Operating Temperature

-5 C to +55 C

-5 C to +55 C

Working pressure

15 bar

15 bar

Maximum Service Pressure

1.8 MPa

1.8 MPa

Test Pressure

35 bar

35 bar

Average Discharge Time

20

25

Discharge Range

<4

<4

Fire Rating

2A,34B

3A,55B

MODEL NO

SE-CW-6

SE-CW-9

Capacity

6

9

Diameter ( mm)

150

175

Height ( mm)

500

630

Empty Weight (kg )

5.1

7.6

Filled Weight (kg)

11.1

16.6

Operating Temperature

-5 C to +55 C

-5 C to +55 C

Working pressure

15 bar

15 bar

Maximum Service Pressure

2.1 MPa

2.1 MPa

Test Pressure

35 bar

35 bar

Average Discharge Time

20

25

Discharge Range

<4

<4

Fire Rating

2A.21B

3A,34B

MODEL

SE-T-MF-C- 50

Capacity

50

Dia

300

Thickness

3.15

Hydraulic test pressure

30

Jet range

10

Min period for which jet is maintained

60

Max period to discharge

180

Min discharge quantity

95

Height

1200

Empty weight

37.8

Filled weight

85

Working temperature

+5 C to +55 C
