Trolley Mounted Carbon Dioxide Extinguisher
Product Details:
Product Description
Specification :
Stored Pressure Type
| MODEL NO | SE-C02-2 | SE-C02- 3 | SE-C02- 4.5 |
| Capacity | 2 | 3 | 4.5 |
| Diameter ( mm) | 108 | 140 | 140 |
| Height ( mm) | 580 | 545 | 705 |
| Empty Weight (kg ) | 6.2 | 9.9 | 12.4 |
| Filled Weight (kg) | 8.2 | 12.9 | 16.9 |
| Operating Temperature | -30 C to +55 C | -30 C to +55 C | -30 C to +55 C |
| Maximum Service Pressure | 16.9 MPa | 16.9 MPa | 16.9 MPa |
| Test Pressure | 250 bar | 250 bar | 250 bar |
| Average Discharge Time | 9 | 9 | 10 |
| Fire Rating | 8B | 13B | 34B |
Trolley Mounted Carbon Dioxide
| MODEL | SE-T-C02-6.5 | SE-T-C02-9 | SE-T-C02-22.5 |
| Capacity | 6.5 | 9 | 22.5 |
| Dia | 140 | 140 | 232 |
| Thickness | 4.2 | 4.2 | 5.5 |
| Hydraulic test pressure | 250 | 250 | 250 |
| Jet range | 2.5 | 2.5 | 2.5 |
| Min period for which jet is maintained | 10 | 15 | 20 |
| Max period to discharge | 20 | 36 | 60 |
| Min discharge quantity | 95 | 95 | 95 |
| Height | 855 | 1110 | 1030 |
| Empty weight | 14.9 | 19 | 42 |
| Filled weight | 21.4 | 28 | 64.5 |
| Working temperature | -30 C to +55 C | -30 C to +55 C | -30 C to +55 C |
