ABC Dry Powder Fire Extinguishers

Product Details:

Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Product Description

ABC Dry Powder Fire Extinguishers used a specially fluidized and siliconized mono ammonium phosphate dry chemical. Our offered fire extinguisher has stored pressure design, dependable deep drawn steel cylinders, durable high gloss powder coating and brass valve chrome plated heavy duty features. Our offered fire extinguisher is widely applicable in homes, offices, buildings, warehouses and cinema halls. At every phase of production, these ABC Dry Powder Fire Extinguishers are examined in order to remove any possible fault from these fire extinguishers. Industry approved design, rust free body and zero maintenance are qualities of offered product.

Stored Pressure Type :

MODEL NO	SE-SP-ABC-1	SE-SP-ABC-2	SE-SP-ABC-4	SE-SP-ABC-6	SE-SP-ABC-9
Capacity	1	2	4	6	9
Diameter ( mm)	86.5	108	130	150	175
Height ( mm)	340	395	485	550	605
Empty Weight (kg )	1.3	1.8	2.8	3.5	4.7
Filled Weight (kg)	2.3	3.8	6.8	9.5	13.7
Operating Temperature	-20 C to +55 C	-20 C to +55 C	-20 C to +55 C	-20 C to +55 C	-20 C to +55 C
Working pressure	15 bar	15 bar	15 bar	15 bar	15 bar
Maximum Service Pressure	1.8 MPa	1.8 MPa	1.8 MPa	1.8 MPa	1.8 MPa
Test Pressure	35 bar	35 bar	35 bar	35 bar	35 bar
Average Discharge Time	8	11	15	20	25
Discharge Range	<2	<2	<4	<4	<4
Fire Rating	1A,8B	1A,13B	2A, 21B	3A,21B	3A,55B

Cartridge Type :

MODEL NO	SE-SP-ABC-6	SE-SP-ABC-9
Capacity	6	9
Diameter ( mm)	150	175
Height ( mm)	495	630
Empty Weight (kg )	5.1	7.1
Filled Weight (kg)	11.1	16.1
Operating Temperature	-30 C to +55 C	-30 C to +55 C
Working pressure	15 bar	15 bar
Maximum Service Pressure	1.8 MPa	1.8 MPa
Test Pressure	35 bar	35 bar
Average Discharge Time	20	25
Discharge Range	<4	<4
Fire Rating	3A,34B	4A,55B
